Efficient Airflow Solution for Compact Ventilation Systems
SZR's 100mm DC centrifugal fans are engineered for medium-volume cooling applications requiring concentrated airflow and stable pressure performance. The compact blower structure supports continuous heat dissipation inside confined industrial and electronic systems while maintaining low power consumption and operational stability.
Mechanical Structure
The fan frame adopts reinforced die-cast aluminum construction with anti-oxidation surface treatment for improved durability in industrial environments. The impeller is produced from high-strength UL94V-0 thermoplastic material to ensure dimensional precision and fire resistance.
Its centrifugal airflow design accelerates air through a side exhaust channel, helping improve cooling efficiency where axial airflow is insufficient. Internal balancing treatment minimizes vibration during high-speed operation and supports long-term thermal stability.
Technical Specifications
|
Parameter |
Specification |
|
Dimension |
100×100×45 mm |
|
Rated Voltage |
12V / 24V DC |
|
Speed Range |
2200-3600 RPM |
|
Airflow Capacity |
38-68 CFM |
|
Static Pressure |
1.8-3.5 inch-H2O |
|
Noise Level |
32-45 dB(A) |
|
Bearing Type |
Dual Ball Bearing |
|
Motor Protection |
Locked Rotor Protection |
|
Insulation Class |
Class B |
|
Operating Temperature |
-10°C to +70°C |
|
Frame Material |
Aluminum Alloy |
|
Impeller Material |
PBT UL94V-0 |
|
Protection Level |
IP54 / IP65 Optional |
|
Certifications |
CE, RoHS, ISO9001 |
Product Features
• Concentrated airflow output for restricted ventilation channels
• Stable DC motor operation with low starting current
• Reduced turbulence and smoother air delivery
• Compact centrifugal structure for limited spaces
• Long operational lifespan with ball bearing system
• Custom wire terminals and PWM speed control available
Typical Applications
• Industrial control cabinets
• Communication equipment
• Medical analyzers
• Laser cooling systems
• Battery management modules
• Small HVAC air circulation units
• Electronic heat dissipation systems
Frequently Asked Questions
Q: Is PWM speed regulation supported?
A: Yes. Optional PWM control configurations are available for intelligent speed adjustment.
Q: Can the fan be installed horizontally?
A: Yes. Dual ball bearing construction supports multi-directional installation.
Q: Is waterproof protection available?
A: Optional IP65 protection can be provided for humid or dusty environments.
Q: Does SZR support OEM specifications?
A: Customized voltage, cable length, connector type and airflow settings are available.
Engineering Service
SZR provides customized DC centrifugal cooling solutions for industrial and electronic ventilation projects. Rapid sampling, technical optimization and OEM manufacturing support are available according to project requirements.
